1.6.30
at the heart of both the R2 and WR2 series, the hbC controller makes simultaneous
HBC Controllers
heating and cooling possible. improved system efficiency is achieved when energy
is transferred intelligently around the building.
Key Features
Valves, pumps and heat exchangers all contained within the HBC
Manageable phased installation through modular system design
Cat A to Cat B is simple through HBC system design
Intuitive load adjusting flow control valves, inverter driven pumps and heat recovery for maximum efficiency
MASTER HBC CONTROLLERS
CMB-WM108V-AA
CMB-WM1016V-AA
NUMbER Of CONNECTiONs
8
16
WEighT (kg)
86 (96)*
98 (111)*
diMENsiONs (mm)
Width
1520
1800
Depth (Control Box)
540 (630)
540 (630)
Height
300
300
ElECTRiCal sUpply
220-240v, 50hz
220-240v, 50hz
phasE
single
single
pOWER iNpUT (kW)
0.46
0.47
RUNNiNg CURRENT (a)
2.83
2.89
fUsE RaTiNg (bs88) - hRC (a)
6
6
MaiNs CablE No. Cores
3
3
SUB HBC CONTROLLERS
CMB-WM108V-AB
CMB-WM1016V-AB
NUMbER Of CONNECTiONs
8
16
WEighT (kg)
44 (49)*
53 (62)*
diMENsiONs (mm)
Width
1520
1520
Depth (Control Box)
540 (630)
540 (630)
Height
300
300
ElECTRiCal sUpply
220-240v, 50hz
220-240v, 50hz
phasE
single
single
pOWER iNpUT (kW)
0.01
0.01
RUNNiNg CURRENT (a)
0.05
0.05
fUsE RaTiNg (bs88) - hRC (a)
6
6
MaiNs CablE No. Cores
3
3
Notes: CMB-WM-V-AA and CMB-WM-V-AB units are for use with PURY-(E)M200-500YNW-A1, PQRY-P200-500YLM-A1 units and HVRF indoor units only.
One main HBC can be used on outdoor units PURY-(E)M200-250YNW-A1, PQRY-P200-250YNW-A1. One main HBC can be used on outdoor units PURY-(E)M300-350YNW-A1, PQRY-P300-350YLM-A1 with a system efficiency reduction.
Two main HBC’s can be used in parallel on outdoor units PURY-(E)M300-500YNW-A1, PQRY-P300-500YLM-A1. PURY-(E)M400-500YNW-A1 requires 2No. Main HBC’s
*(
) Includes Water
Product Dimensions CMB-WM108V-AA
Product Dimensions CMB-WM1016V-AA
1379
1659
(Lifting bolt pitch)
(Lifting bolt pitch)
Upper View
Control box
Upper View
Control box
44
44
157
157
216
216
224
224
272
272
286
286
1321
1601
1391
1671
1520
1800
412
70X7=490
412
70X15=1050
70
70
Side View
Side View
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
70
70
447
70X7=490
447
70X15=1050
Product Dimensions CMB-WM108V-AB
Product Dimensions CMB-WM1016V-AB
1379
1379
(Lifting bolt pitch)
(Lifting bolt pitch)
Upper View
Upper View
Control box
Control box
44
149
44
219
149
1520
219
1520
290
70X7=490
290
70X15=1050
70
70
Side View
Side View
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
9
10 11 12 13 14 15 16
70
70
325
70X7=490
325
70X15=1050
1.6.31
Air Conditioning
HBC Controllers (HVRF)
