ideal where outdoor space is limited, building heat recovery and efficiency is demanded and a water loop is
WR2 Series HVRF
available, City Multi WR2 Water Cooled models provide the ultimate solution for the majority of applications
including hotels, offices, leisure, retail and high end residential.
(22.4-56kW)
first developed 25 years ago, the City Multi Water Cooled system utilises water instead of air as an energy transfer medium,
but benefits from all the same technology and flexibility of an air sourced VRf.
Simultaneous Heating and Cooling
Key Features
with Double Heat Recovery,
Water Cooled Condensing Unit
■ High efficiency, modular systems, with ability to recover energy between units on the water circuit,
in either a closed or open loop building, or ground source application
■ Benefits from a wide indoor unit range and advanced control options
■ Very low impact footprint and service space requirements, ideal for internal location
PQRY-P
PQRY-
PQRY-
PQRY-P300YLM-A1
PQRY-
PQRY-P350YLM-A1
PQRY-
PQRY-
PQRY-
CONDENSING UNITS
200YLM-A1
P250YLM-A1
P300YLM-A1
( 2 x MAiN )
P350YLM-A1
( 2 x MAiN )
P400YLM-A1
P450YLM-A1
P500YLM-A1
CapaCiTy (kW)
Heating (nominal)
25.0
31.5
37.5
37.5
45.0
45.0
50.0
56.0
63.0
Cooling (nominal)
22.4
28.0
33.5
33.5
40.0
40.0
45.0
50.0
56.0
pOWER iNpUT (kW)
Heating (nominal)
4.04
5.41
7.13
6.79
8.87
8.25
9.45
11.11
13.07
Cooling (nominal)
3.97
5.44
7.55
6.71
9.98
8.72
10.05
12.05
14.58
OpERaTiNg WaTER VOlUME (m3/h)
3.0 ~ 7.2
3.0 ~ 7.2
3.0 ~ 7.2
3.0 ~ 7.2
4.5 ~ 11.6
4.5 ~ 11.6
4.5 ~ 11.6
4.5 ~ 11.6
4.5 ~ 11.6
gUaRaNTEEd OpERaTiNg RaNgE (ºC) Heating / Cooling
-5~45 / -5~45
10~45 / -5~45
-5~45 / -5~45
-5~45 / -5~45
-5~45 / -5~45
-5~45 / -5~45
-5~45 / -5~45
-5~45 / -5~45
-5~45 / -5~45
COp / EER (nominal)
6.18 / 5.64
5.82 / 5.14
5.25 / 4.43
5.52 / 4.99
5.07 / 4.00
5.45 / 4.58
5.29 / 4.47
5.04 / 4.14
4.82 / 3.84
MaX NO. Of CONNECTablE iNdOOR UNiTs
20
25
30
30
35
35
40
45
50
MaX CONNECTablE CapaCiTy
50 ~ 150%
50 ~ 150%
50 ~ 150%
50 ~ 150%
50 ~ 150%
50 ~ 150%
50 ~ 150%
50 ~ 150%
50 ~ 150%
pipE siZE mm (in)
Gas
19.05 (3/4")
22.2 (7/8")
22.2 (7/8")
22.2 (7/8")
28.58 (1 1/8")
28.58 (1 1/8")
28.58 (1 1/8")
28.58 (1 1/8")
28.58 (1 1/8")
Liquid
15.88 (5/8")
19.05 (3/4")
19.05 (3/4")
19.05 (3/4")
22.2 (7/8")
22.2 (7/8")
22.2 (7/8")
22.2 (7/8")
22.2 (7/8")
sOUNd pREssURE lEVEl (dba)
46
48
54
54
52
52
52
54
54
sOUNd pOWER lEVEl (dba)
60
62
68
68
66
66
66
70
70.5
WEighT (kg)
172
172
172
172
216
216
216
216
216
diMENsiONs (mm)
Width
880
880
880
880
880
880
880
880
880
Depth
550
550
550
550
550
550
550
550
550
Height
1100
1100
1100
1100
1450
1450
1450
1450
1450
ElECTRiCal sUpply*1
380-415v, 50hz
380-415v, 50hz
380-415v, 50hz
380-415v, 50hz
380-415v, 50hz
380-415v, 50hz
380-415v, 50hz
380-415v, 50hz
380-415v, 50hz
phasE*1
Three
Three
Three
Three
Three
Three
Three
Three
Three
sTaRTiNg CURRENT (a)
8
8
8
8
8
8
8
8
8
NOMiNal sysTEM RUNNiNg CURRENT (a)*1 Heating / Cooling [MAX]
6.1 / 5.7 [16.1]
7.8 / 7.5 [16.1]
9.6 / 9.3 [18.6]
9.6 / 9.3 [18.6]
11.6 / 11.0 [23.1]
11.6 / 11.0 [23.1]
12.9 / 12.4 [27.6]
15.1 / 14.3 [32.9]
17.6 / 17.2 [39.2]
fUsE RaTiNg (bs88) - hRC (a)*1
1 x 20
1 x 20
1 x 20
1 x 20
1 x 25
1 x 25
1 x 32
1 x 40
1 x 40
MaiNs CablE No. Cores*1
4 + earth
4 + earth
4 + earth
4 + earth
4 + earth
4 + earth
4 + earth
4 + earth
4 + earth
ChaRgE REfRigERaNT (kg) / CO2 EQUiValENT (t)
5.0 / 10.4
5.0 / 10.4
5.0 / 10.4
5.0 / 10.4
6.0 / 12.5
6.0 / 12.5
6.0 / 12.5
6.0 / 12.5
6.0 / 12.5
R410A (GWP 2088)
MaX addiTiONal REfRigERaNT (kg) / CO2 EQUiValENT (t)
27.0 / 56.4
32.0 / 66.8
33.0 / 68.9
33.0 / 68.9
52.0 / 108.6
52.0 / 108.6
52.0 / 108.6
53.0 / 110.7
55.0 / 114.8
R410A (GWP 2088)
Notes: *SEER/SCOP available separately in the 'City Multi HVRF Seasonal Efficiency' document. Based on Ecodesign Lot 21/6 to EN14825 standard.
*1 A separate power supply is required for each module. Where more than one figure is quoted there are multiple modules.
