1.6.26
an elegant design combined with compact dimensions and quiet operation make the pKfy-Wl an
PKFY-WL-VLM-E
ideal indoor unit choice. Noise levels are significantly reduced compared to the previous models.
Wall Mounted
Key Features
indoor Unit
Compact flat panel design - only 773mm wide (sizes 10-32)
Widened vane control for improved air distribution and comfort
Reduced noise levels of 22dB(A) (sizes 10-25)
INDOOR UNITS
PKFY-WL10VLM-E
PKFY-WL15VLM-E
PKFY-WL20VLM-E
PKFY-WL25VLM-E
PKFY-WL32VLM-E
PKFY-WL40VLM-E
CapaCiTy (kW)
Heating (nominal)
1.4
1.9
2.5
3.2
4.0
5.0
Cooling (nominal)
1.2
1.7
2.2
2.8
3.6
4.5
UK Heating
1.4
1.9
2.5
3.2
4.0
5.0
UK Total Cooling - Hi (Sensible)
1.10
(1.02)
1.50
(1.20)
2.00
(1.56)
2.50
(1.95)
3.20
(2.60)
4.10
(3.16)
UK Total Cooling - Mi2
1.08
1.50
1.98
2.47
3.16
4.01
UK Total Cooling - Mi1
1.07
1.48
1.94
2.43
3.13
3.90
UK Total Cooling - Lo
1.03
1.48
1.91
2.38
3.03
3.81
pOWER iNpUT (kW)
Heating (nominal)
0.01
0.01
0.02
0.03
0.03
0.04
Cooling (nominal)
0.02
0.02
0.03
0.04
0.04
0.05
aiRflOW (l/s)
Lo-Mi1-Mi2-Hi
55-63-68-75
55-63-72-82
67-83-100-117
67-90-117-140
105-127-150-173
107-137-167-198
sOUNd pREssURE lEVEl (dba) Lo-Mi1-Mi2-Hi
22-26-28-30
22-26-29-32
22-28-33-36
22-30-36-41
29-34-38-41
30-36-41-45
WEighT (kg)
25
25
25
25
29
29
diMENsiONs (mm)
Width
773
773
773
773
898
898
Depth
237
237
237
237
237
237
Height
299
299
299
299
299
299
ElECTRiCal sUpply
220-240v, 50hz
220-240v, 50hz
220-240v, 50hz
220-240v, 50hz
220-240v, 50hz
220-240v, 50hz
phasE
single
single
single
single
single
single
RUNNiNg CURRENT (a) Heating / Cooling
0.15 / 0.20
0.15 / 0.20
0.20 / 0.25
0.30 / 0.35
0.30 / 0.35
0.40 / 0.45
fUsE RaTiNg (bs88) - hRC (a)
6
6
6
6
6
6
MaiNs CablE No. Cores
3
3
3
3
3
3
Note: HVRF indoor units can only be configured with the CMB-WM HBC (HVRF) and PURY-(E)M YNW-A1 or PQRY-P YLM-A1 outdoor units.
Product Dimensions PKFY-WL10/15/20/25VLM-E
Front View
Side View
Product Dimensions PKFY-WL32/40VLM-E
Front View
Side View
1.6.27
Air Conditioning
PKFY-WL-VLM-E Wall Mounted indoor Unit
