1.6.18
The ultra thin ceiling concealed ducted indoor unit offers increased flexibility and is particularly
PEFY-WP-VMS1-E
suitable for locations where low noise operation is desired from a slimline body, such as hotels.
Ultra Thin Ceiling Concealed
Ducted indoor Unit
Key Features
Ultra thin body - height of only 200mm & width of only 790mm (size WP10-25)
Extremely quiet operation - as low as 22dBA (size WP10-20)
Static pressure of 5-50Pa
Available in 1.1 and 1.5kW sizes, which are ideal for hotel rooms
INDOOR UNITS
PEFY-WP10VMS1-E
PEFY-WP15VMS1-E
PEFY-WP20VMS1-E
PEFY-WP25VMS1-E
PEFY-WP32VMS1-E
PEFY-WP40VMS1-E
PEFY-WP50VMS1-E
CapaCiTy (kW)
Heating (nominal)
1.4
1.9
2.5
3.2
4.0
5.0
6.3
Cooling (nominal)
1.2
1.7
2.2
2.8
3.6
4.5
5.6
UK Heating
1.4
1.9
2.5
3.2
4.0
5.0
6.3
UK Total Cooling - Hi (Sensible)
1.10
(1.00)
1.50
(1.50)
2.00
(1.70)
2.50
(2.00)
3.20
(2.70)
4.00
(3.20)
5.00
(4.00)
UK Total Cooling - Mi2
-
-
-
-
-
-
-
UK Total Cooling - Mi1
1.07
1.44
1.89
2.32
3.03
3.82
4.78
UK Total Cooling - Lo
1.03
1.34
1.76
2.08
2.88
3.61
4.51
pOWER iNpUT (kW)
Heating (nominal)
0.03
0.03
0.03
0.04
0.05
0.07
0.07
Cooling (nominal)
0.03
0.05
0.05
0.06
0.07
0.09
0.09
aiRflOW (l/s)
Lo-Mi-Hi
67-75-83
83-100-117
92-108-133
92-117-150
133-150-183
158-183-217
200-233-275
EXTERNal sTaTiC pREssURE (Pa)
5-15-35-50
5-15-35-50
5-15-35-50
5-15-35-50
5-15-35-50
5-15-35-50
5-15-35-50
sOUNd pREssURE lEVEl (dba) Lo-Mi-Hi
22-23-25
22-24-28
22-25-29
23-26-30
28-30-33
30-32-35
30-33-36
WEighT (kg)
19
19
20
20
25
25
27
diMENsiONs (mm)
Width
790
790
790
790
990
990
1190
Depth
700
700
700
700
700
700
700
Height
200
200
200
200
200
200
200
ElECTRiCal sUpply
220-240v, 50hz
220-240v, 50hz
220-240v, 50hz
220-240v, 50hz
220-240v, 50hz
220-240v, 50hz
220-240v, 50hz
phasE
single
single
single
single
single
single
single
RUNNiNg CURRENT (a) Heating / Cooling
0.33 / 0.21
0.33 / 0.44
0.38 / 0.49
0.40 / 0.51
0.50 / 0.61
0.62 / 0.73
0.66 / 0.77
fUsE RaTiNg (bs88) - hRC (a)
6
6
6
6
6
6
6
MaiNs CablE No. Cores
3
3
3
3
3
3
3
WaTER pipE CONNECTiON
3/4" bsp sCREW
3/4" bsp sCREW
3/4" bsp sCREW
3/4" bsp sCREW
3/4" bsp sCREW
3/4" bsp sCREW
3/4" bsp sCREW
Note: HVRF indoor units can only be configured with the CMB-WM HBC (HVRF) and PURY-(E)M YNW-A1 or PQRY-P YLM-A1 outdoor units.
Product Dimensions PEFY-WP10/15/20/25/32/40/50VMS1-E
Upper View
Front View
20
D (Duct)
30
100×(E-1)=F
20
G
64
100
12
88
100×H=J
88
100
Side View
700
23
677
2
Water pipe(To HBC unit)
270
Rc3/4 screw
10
Drain pipe
(O.D.ø32)
To
From
HBC Unit HBC Unit
90
A
116
70
M
1
Water pipe(From HBC unit)
270
Drain pipe(O.D.ø32)
23
B (Suspension bolt pitch)
Rc3/4 screw
(Spontaneous draining)
C
L
1
Water pipe
2
Water pipe
Model
A
B
C
D
E
F
G
H
J
K
L
M
(From HBC unit)
(To HBC unit)
PEFY-WP10VMS1-E
PEFY-WP15VMS1-E
700
752
798
660
7
600
660
5
500
16
839
790
PEFY-WP20VMS1-E
Rc3/4 screw
PEFY-WP25VMS1-E
PEFY-WP32VMS1-E
900
952
998
860
9
800
860
7
700
20
1039
990
PEFY-WP40VMS1-E
PEFY-WP50VMS1-E
1100
1152
1198
1060
11
1000
1060
9
900
24
1239
1190
1.6.19
Air Conditioning
PEFY-WP-VMS1-E Ultra Thin Ceiling Concealed Ducted indoor Unit
