1.6.22

The new plfy-Wl-VEM-E offers 72 different airflow patterns, with the ability to handle a multitude of ceiling

PLFY-WL-VEM-E

applications up to 4.2 metres in height. The easy to install, slim unit is ideal for maintaining constant

temperatures, thanks to adjustable vanes that allow users to precisely direct air where it’s needed.

4-Way Blow Ceiling Cassette

Key Features

indoor Unit

Improved airflow control, including horizontal airflow for greater comfort (compared to the previous VBM model)

Optional 3D i-see sensor grille (PLP-6EAE) provides customised comfort by automatically monitoring room occupancy,

position and body temperatures

Optional filter lowering operation down to 4m (PLP-6EAJ)

INDOOR UNITS

PLFY-WL32VEM-E

PLFY-WL40VEM-E

PLFY-WL50VEM-E

CapaCiTy (kW)

Heating (nominal)

4.0

5.0

6.3

Cooling (nominal)

3.6

4.5

5.6

UK Heating

4.0

5.0

6.3

UK Total Cooling - Hi (Sensible)

3.20

(3.20)

4.00

(3.60)

5.00

(4.20)

UK Total Cooling - Mi2

3.16

3.95

4.87

UK Total Cooling - Mi1

3.09

3.87

4.66

UK Total Cooling - Lo

3.02

3.77

4.39

pOWER iNpUT (kW)

Heating (nominal)

0.03

0.04

Cooling (nominal)

0.03

0.04

aiRflOW (l/s)

Lo-Mi1-Mi2-Hi

233-250-267-283

233-267-300-333

sOUNd pREssURE lEVEl (dba) Lo-Mi1-Mi2-Hi

26-27-29-30

26-28-29-31

27-29-31-33

WEighT (kg)

diMENsiONs (mm)

Width (Grille)

840 (950)

Depth (Grille)

840 (950)

Height (Grille)

258 (40)

ElECTRiCal sUpply

220-240v, 50hz

phasE

single

RUNNiNg CURRENT (a) Heating / Cooling

0.27 / 0.33

0.29 / 0.35

0.34 / 0.40

fUsE RaTiNg (bs88) - hRC (a)

MaiNs CablE No. Cores

gRillE MOdEl REfERENCE

plp-6Ea

WaTER pipE CONNECTiON

20mm i.d

Note: HVRF indoor units can only be configured with the CMB-WM HBC (HVRF) and PURY-(E)M YNW-A1 or PQRY-P YLM-A1 outdoor units.

1.6.24

The plfy-Wl-VfM-E cassette unit provides the smart solution to comfortable and efficient air conditioning.

PLFY-WL-VFM-E

it combines a stylish square design slimline grille with the latest energy-saving technologies and

is designed to fit snugly to ceilings making it ideal in both offices and retail.

600x600 4-Way Blow

Key Features

Ceiling Cassette indoor Unit

New design - fits into narrow ceiling spaces with height of only 245mm

Low noise levels - reduced noise value with 3D turbo fan

Horizontal airflow - eliminating uncomfortable drafts and improved airflow control

Easy installation - temporary hanging hook on grille and no screw removal for corner panel / control box

Optional 3D i-see sensor grille (SLP-2FAE) provides customised comfort by automatically monitoring room occupancy,

position and body temperatures

INDOOR UNITS

PLFY-WL15VFM-E

PLFY-WL20VFM-E

PLFY-WL25VFM-E

PLFY-WL32VFM-E

CapaCiTy (kW)

Heating (nominal)

1.9

2.5

3.2

4.0

Cooling (nominal)

1.7

2.2

2.8

3.6

UK Heating

1.9

2.5

3.2

4.0

UK Total Cooling - Hi (Sensible)

1.50

(1.30)

2.00

(1.60)

2.50

(2.00)

3.20

(2.60)

UK Total Cooling - Mi1

1.44

1.92

2.38

2.92

UK Total Cooling - Lo

1.36

1.89

2.26

2.52

pOWER iNpUT (kW)

Heating (nominal)

0.02

0.03

0.04

Cooling (nominal)

0.02

0.03

0.04

aiRflOW (l/s)

Lo-Mi-Hi

100-115-135

110-115-135

110-125-150

110-150-200

sOUNd pREssURE lEVEl (dba) Lo-Mi-Hi

25-26-29

27-29-31

27-30-34

27-33-41

WEighT (kg)

(Grille)

13 (3)

14 (3)

diMENsiONs (mm)

Width (Grille)

570 (625)

Depth (Grille)

570 (625)

Height (Grille)

245 (10)

ElECTRiCal sUpply

220-240v, 50hz

phasE

single

RUNNiNg CURRENT (a)

Heating / Cooling

0.18 / 0.24

0.20 / 0.26

0.23 / 0.29

0.32 / 0.38

fUsE RaTiNg (bs88) - hRC (a)

MaiNs CablE No. Cores

gRillE MOdEl REfERENCE

slp-2fa

WaTER pipE CONNECTiON

20mm i.d

Note: HVRF indoor units can only be configured with the CMB-WM HBC (HVRF) and PURY-(E)M YNW-A1 or PQRY-P YLM-A1 outdoor units.
