1.5.56

ideal where outdoor space is limited, building heat recovery and efficiency is demanded and a water loop is

WY Series

available, City Multi Wy Water Cooled models provide the ultimate solution for open plan spaces.

(22.4-56kW)

first developed 25 years ago, the City Multi Water Cooled system utilises water instead of air as an energy transfer medium,

but benefits from all the same technology and flexibility of an air sourced VRf.

Heat Pump, Water Cooled

Key Features

Condensing Unit

■ High efficiency, modular systems, with ability to recover energy between units on the water circuit,

in either a closed or open loop building, or ground source application

■ Benefits from a wide indoor unit range and advanced control options

■ Very low impact footprint and service space requirements, ideal for internal location

PQHY-

CONDENSING UNITS

P200YLM-A1

P250YLM-A1

P300YLM-A1

P350YLM-A1

P400YLM-A1

P400YSLM-A1

P450YLM-A1

P450YSLM-A1

P500YLM-A1

P500YSLM-A1

CapaCiTy (kW)

Heating (nominal)

25.0

31.5

37.5

45.0

50.0

56.0

63.0

Cooling (nominal)

22.4

28.0

33.5

40.0

45.0

50.0

56.0

pOWER iNpUT (kW)

Heating (nominal)

3.97

5.08

6.25

7.53

8.37

7.94

9.79

6.24

11.43

10.16

Cooling (nominal)

3.71

4.90

6.04

7.14

8.03

7.70

9.29

5.69

11.17

10.12

OpERaTiNg WaTER VOlUME (m³/h)

3.0 ~ 7.2

4.5 ~ 11.6

3.0 + 3.0 ~ 7.2 + 7.2

4.5 ~ 11.6

3.0 + 3.0 ~ 7.2 + 7.2

4.5 ~ 11.6

3.0 + 3.0 ~ 7.2 + 7.2

gUaRaNTEEd OpERaTiNg RaNgE (ºC) Heating / Cooling

-5~45 / -5~45

COp / EER (nominal)

6.29 / 6.03

6.20 / 5.71

6.25 / 5.54

5.97 / 5.60

6.29 / 5.84

5.72 / 5.38

6.24 / 5.69

5.51 / 5.01

6.20 / 5.53

MaX NO. Of CONNECTablE iNdOOR UNiTs

MaX CONNECTablE CapaCiTy

50 ~ 130%

pipE siZE mm (in)

Gas

19.05 (3/4")

22.2 (7/8")

28.58 (1 1/8")

Liquid

9.52 (3/8")

9.52 (3/8")**

12.7 (1/2")

15.88 (5/8")

sOUNd pREssURE lEVEl (dba)

sOUNd pOWER lEVEl (dba)

70.5

WEighT (kg)

174

217

174 + 174

217

174 + 174

217

174 + 174

diMENsiONs (mm)

Width

880

880 + 880

880

880 + 880

880

880 + 880

Depth

550

Height

1100

1450

1100

1450

1100

1450

1100

ElECTRiCal sUpply^*2

380-415v, 50hz

phasE*2

Three

sTaRTiNg CURRENT (a)

8 / 8

NOMiNal sysTEM RUNNiNg CURRENT (a)*2 Heating / Cooling [MAX]

6.1 / 5.7 [16.1]

7.8 / 7.5 [16.1]

9.6 / 9.3 [18.6]

11.6 / 11.0 [23.1]

12.9 / 12.4 [27.6]

12.2 / 11.9 [16.1 + 16.1]

15.1 / 14.3 [32.9]

13.8 / 13.5 [16.1 + 16.1]

17.6 / 17.2 [39.2]

15.7 / 15.6 [16.1 + 16.1]

fUsE RaTiNg (bs88) - hRC (a)*2

1 x 20

1 x 25

1 x 32

1 x 20 / 1 x 20

1 x 40

1 x 20 / 1 x 20

1 x 40

1 x 20 / 1 x 20

MaiNs CablE No. Cores*2

4 + earth

ChaRgE REfRigERaNT (kg) / CO2 EQUiValENT (t)

5.0 / 10.4

6.0 / 12.5

10.0 / 20.9

6.0 / 12.5

10.0 / 20.9

6.0 / 12.5

10.0 / 20.9

R410A (GWP 2088)

MaX addiTiONal REfRigERaNT (kg) / CO2 EQUiValENT (t)

R410A (GWP 2088)

21.0 / 43.8

28.0 / 58.5

29.5 / 61.6

41.5 / 86.7

50.0 / 104.4

51.5 / 107.5

53.5 / 111.7

Notes: *SEER/SCOP available separately in the 'City Multi VRF Seasonal Efficiency' document. Based on Ecodesign Lot 21/6 to EN14825 standard. *1 A separate power supply is required for each module.

Where more than one figure is quoted there are multiple modules. These products are made to order, please consult your local sales office for delivery schedule.

PIPING RESTRICTIONS

PQHY-P200-500Y(S)LM-A1

TOTal pipiNg lENgTh

300m max for sizes 200-300 / 500m for sizes 350-900

fURThEsT pipiNg lENgTh

165m max

fURThEsT pipiNg lENgTh afTER 1sT bRaNCh

40m max

bETWEEN iNdOOR aNd OUTdOOR UNiTs - hEighT

50m max (40m max if outdoor installed below)

bETWEEN iNdOOR aNd iNdOOR UNiTs - hEighT

15m max

1.5.58

ideal where outdoor space is limited, building heat recovery and efficiency is demanded and a water loop is

WY Series

available, City Multi Wy Water Cooled models provide the ultimate solution for open plan spaces.

(63-101kW)

first developed 25 years ago, the City Multi Water Cooled system utilises water instead of air as an energy transfer medium,

but benefits from all the same technology and flexibility of an air sourced VRf.

Heat Pump, Water Cooled

Key Features

Condensing Unit

■ High efficiency, modular systems, with ability to recover energy between units on the water circuit,

in either a closed or open loop building, or ground source application

■ Benefits from a wide indoor unit range and advanced control options

■ Very low impact footprint and service space requirements, ideal for internal location

PQHY-

CONDENSING UNITS

P550YLM-A1

P550YSLM-A1

P600YLM-A1

P600YSLM-A1

P700YSLM-A1

P750YSLM-A1

P800YSLM-A1

P850YSLM-A1

P900YSLM-A1

CapaCiTy (kW)

Heating (nominal)

69.0

76.5

88.0

95.0

100.0

108.0

113.0

Cooling (nominal)

63.0

69.0

80.0

85.0

90.0

96.0

101.0

pOWER iNpUT (kW)

Heating (nominal)

12.27

11.31

14.51

12.75

14.73

15.90

16.75

18.49

19.74

Cooling (nominal)

12.54

11.55

14.49

12.84

14.73

15.64

16.57

18.03

19.38

OpERaTiNg WaTER VOlUME (m³/h)

6.0 ~ 14.4

3.0 + 3.0 ~ 7.2 + 7.2

6.0 ~ 14.4

3.0 + 3.0 ~ 7.2 + 7.2

4.5 + 4.5 ~ 11.6 + 11.6

gUaRaNTEEd OpERaTiNg RaNgE (ºC) Heating / Cooling

-5~45 / -5~45

COp / EER (nominal)

5.62 / 5.02

6.10 / 5.45

5.27 / 4.76

6.00 / 5.37

5.97 / 5.43

5.84 / 5.32

5.72 / 5.21

MaX NO. Of CONNECTablE iNdOOR UNiTs

MaX CONNECTablE CapaCiTy

50 ~ 130%

pipE siZE mm (in)

Gas

28.58 (1 1/8")

34.93 (1 3/8")

41.28 (1 5/8")

Liquid

15.88 (5/8")

19.05 (3/4")

sOUNd pREssURE lEVEl (dba)

56.5

sOUNd pOWER lEVEl (dba)

71.5

WEighT (kg)

246

174 + 174

246

174 + 174

217 + 217

diMENsiONs (mm)

Width

880

880 + 880

880

880 + 880

Depth

550

Height

1450

1100

1450

1100

1450

ElECTRiCal sUpply^*1

380-415v, 50hz

phasE*1

Three

sTaRTiNg CURRENT (a)

8 / 8

NOMiNal sysTEM RUNNiNg CURRENT (a)*1 Heating / Cooling [MAX]

18.9 / 19.3 [40.5]

17.4 / 17.8 [18.6 + 16.1]

22.4 / 22.3 [40.5]

19.7 / 19.8 [18.6 + 18.6]

22.7 / 22.7 [23.1 + 23.1]

24.5 / 24.1 [27.6 + 23.1]

25.8 / 25.6 [27.6 + 27.6]

28.5 / 27.8 [32.9 + 27.6]

30.5 / 29.9 [32.9 + 32.9]

fUsE RaTiNg (bs88) - hRC (a)*1

1 x 50

1 x 20 / 1 x 20

1 x 50

1 x 20 / 1 x 20

1 x 25 / 1 x 25

1 x 32 / 1 x 25

1 x 32 / 1 x 32

1 x 40 / 1 x 32

1 x 40 / 1 x 40

MaiNs CablE No. Cores*1

4 + earth

ChaRgE REfRigERaNT (kg) / CO2 EQUiValENT (t)

11.7 / 24.4

10.0 / 20.9

11.7 / 24.4

10.0 / 20.9

12.0 / 25.1

R410A (GWP 2088)

MaX addiTiONal REfRigERaNT (kg) / CO2 EQUiValENT (t)

R410A (GWP 2088)

55.5 / 115.9

54.5 / 113.8

57.0 / 119.0

55.5 / 115.9

65.5 / 136.8

67.5 / 140.9

70.0 / 146.2

Notes: *SEER/SCOP available separately in the 'City Multi VRF Seasonal Efficiency' document. Based on Ecodesign Lot 21/6 to EN14825 standard. *1 A separate power supply is required for each module.

Where more than one figure is quoted there are multiple modules. These products are made to order, please consult your local sales office for delivery schedule.

PIPING RESTRICTIONS

PQHY-P550-900Y(S)LM-A1

TOTal pipiNg lENgTh

500m max

fURThEsT pipiNg lENgTh

165m max

fURThEsT pipiNg lENgTh afTER 1sT bRaNCh

40m max

bETWEEN iNdOOR aNd OUTdOOR UNiTs - hEighT

50m max (40m max if outdoor installed below)

bETWEEN iNdOOR aNd iNdOOR UNiTs - hEighT

15m max
