1.5.80

an elegant design combined with compact dimensions and quiet operation make the pkfy-p

PKFY-P-VLM-E /

an ideal unit choice. Noise levels are significantly lower than previous models.

VKM-E

Wall Mounted

Key Features

Indoor Unit

■ Compact flat panel design - only 773mm wide (sizes 10-32)

■ Widened vane control for improved air distribution and comfort

■ Reduced noise levels of 22dB(A) (sizes 10-25)

INDOOR UNITS

PKFY-P10VLM-E

PKFY-P15VLM-E

PKFY-P20VLM-E

PKFY-P25VLM-E

PKFY-P32VLM-E

PKFY-P40VLM-E

PKFY-P50VLM-E

PKFY-P63VKM-E

CapaCiTy (kW)

Heating (nominal)

1.4

1.9

2.5

3.2

4.0

5.0

6.3

8.0

Cooling (nominal)

1.2

1.7

2.2

2.8

3.6

4.5

5.6

7.1

UK Heating

1.4

1.9

2.5

3.2

4.0

5.0

6.3

8.0

UK Total Cooling - Hi (Sensible)

1.10

(1.00)

1.50

(1.10)

2.00

(1.40)

2.50

(1.80)

3.20

(2.50)

4.10

(3.10)

5.00

(3.60)

6.40

(5.00)

UK Total Cooling - Mi2

1.08

1.50

1.98

2.47

3.16

4.04

4.89

UK Total Cooling - Mi1

1.07

1.48

1.94

2.43

3.13

4.01

4.84

UK Total Cooling - Lo

1.03

1.48

1.91

2.38

3.03

3.81

4.57

6.01

pOWER iNpUT (kW)

Heating (nominal)

0.01

0.02

0.03

0.04

Cooling (nominal)

0.02

0.03

0.04

0.05

aiRflOW (l/s)

Lo-Mi1-Mi2-Hi

55-58-63-70

67-70-73-78

67-73-82-90

67-77-90-112

72-90-115-140

105-123-143-167

113-138-170-207

267-333

sOUNd pREssURE lEVEl (dba) Lo-Mi1-Mi2-Hi

22-24-26-28

22-26-29-31

22-27-31-35

24-31-37-41

29-34-37-40

31-36-41-46

39-45

WEighT (kg)

diMENsiONs (mm)

Width

773

898

1170

Depth

237

295

Height

299

365

ElECTRiCal sUpply

220-240v, 50hz

phasE

single

RUNNiNg CURRENT (a) Heating / Cooling

0.15 / 0.20

0.20 / 0.25

0.30 / 0.35

0.40 / 0.45

0.30 / 0.37

fUsE RaTiNg (bs88) - hRC (a)

MaiNs CablE No. Cores
