1.5.86
in collaboration with Thermoscreens®, Mitsubishi Electric have developed a range of heat pump air curtains
VRF HP DXE
that are able to be connected to our City Multi VRf systems, as opposed to the more traditional direct
electric method associated with air curtains.
Heat Pump Air Curtain
Key Features
■ Reduced CO2 emissions and run costs
■ Allows open door policy in retail outlets whilst being energy efficient
■ Clean indoor environment - protection from external dust, fumes etc.
■ Heat recovery possible, optimising energy use
VRF HP DXE - RECESSED
VRF HP1000R DXE
VRF HP1500R DXE
VRF HP2000R DXE
VRF HP2000R DXE HO*3
CapaCiTy (kW)
Heating (nominal)
8.3
13.2
15.7
21.0
Cooling (nominal)
7.4
11.8
14.0
16.8
aiRflOW MaX (l/s)
364
575
720
720
sOUNd pREssURE lEVEl aT 3m (dba) Lo-Mi1-Hi
50-55-58
49-54-58
50-55-58
50-55-58
WEighT (kg)
52
75
93
93
diMENsiONs (mm)
Width
1250
1750
2340
2340
Depth
348
348
348
348
Height
539
539
539
539
ElECTRiCal sUpply*1
220-240v, 50hz
220-240v, 50hz
220-240v, 50hz
220-240v, 50hz
phasE*1
single
single
single
single
RUNNiNg CURRENT (a)*1
0.8
1.2
1.4
1.4
MaiNs CablE No. Cores*1
3
3
3
3
UNifORMiTy aT OUTlET (%)*2
90
92
90
90
UNiT siZE (index)
p71
p125
p140
p200
MaX MOUNTiNg hEighT (m)
3.2
3.2
3.2
3.2
COMpaTiblE OUTdOOR UNiTs
pUhy / pURy / pQhy / pQRy
pUhy / pURy / pQhy / pQRy
pUhy / pURy / pQhy / pQRy
pUhy / pURy / pQhy / pQRy
VRF HP DXE - FREE STANDING
VRF HP1000 DXE
VRF HP1500 DXE
VRF HP2000 DXE
VRF HP2000 DXE HO*3
CapaCiTy (kW)
Heating (nominal)
8.3
13.2
15.7
21.0
Cooling (nominal)
7.4
11.8
14.0
16.8
aiRflOW MaX (l/s)
364
575
720
720
sOUNd pREssURE lEVEl aT 3m (dba) Lo-Mi1-Hi
50-55-58
49-54-58
50-55-58
50-55-58
WEighT (kg)
46
67
84
84
diMENsiONs (mm)
Width
1300
1825
2350
2350
Depth
468
468
468
468
Height
306
306
306
306
ElECTRiCal sUpply*1
220-240v, 50hz
220-240v, 50hz
220-240v, 50hz
220-240v, 50hz
phasE*1
single
single
single
single
RUNNiNg CURRENT (a)*1
0.8
1.2
1.4
1.4
MaiNs CablE No. Cores*1
3
3
3
3
UNifORMiTy aT OUTlET (%)*2
90
92
90
90
UNiT siZE (index)
p71
p125
p140
p200
MaX MOUNTiNg hEighT (m)
3.2
3.2
3.2
3.2
COMpaTiblE OUTdOOR UNiTs
pUhy / pURy / pQhy / pQRy
pUhy / pURy / pQhy / pQRy
pUhy / pURy / pQhy / pQRy
pUhy / pURy / pQhy / pQRy
Notes: *1 For indoor units with electric defrost heaters enabled, 3ph, 380-415V power supply (7.3A HP1000, 12.1A HP1500, 14.4A HP2000). *2 Tested to ISO27327. *3 Includes twin LEV kit for installation with the air curtain. This model size is made to order.
Product Dimensions VRF HP1000/1500/2000R DXE (HO)
Front View
Upper View
Side View
Liquid Line Refrigerant Connection (L)
Gas Line Refrigerant Connection (G)
A
25
B
C
25
485
E
Additional (M20)
Electrical Supply
Wiring Inlets on top
and Wiring Inlets
(M20)
Holes for M10 drop rods
4 for 1m unit,
5 for 1.5m & 2m units
Liquid Line Refrigerant
Use all drop rod holes !
Connection (L)
20mm hole for gravity or pumped
condensate disposal (if cooling)
20mm hole on top for pumped
Gas Line
CEILING LEVEL
CEILING LEVEL
condensate disposal (if cooling)
Refrigerant
Connection (G)
D
Model
VRf hp1000R dXE
VRf hp1500R dXE
VRf hp2000R dXE
539
a (mm)
1250
1750
2340
b (mm)
-
724
1129
C (mm)
-
976
1161
d (mm)
1303
1803
2393
E (mm)
170
166
189
g
5⁄8 in.
5⁄8 in.
7⁄8 in.
l
1⁄2 in.
1⁄2 in.
5⁄8 in.
Cut-Out
length (mm)
1250
1750
2340
in Ceiling
Width (mm)
485
485
485
Product Dimensions VRF HP1000/1500/2000 DXE (HO)
Front View
Upper View
Side View
Liquid Line
Gas Line
Refrigerant
Refrigerant
Additional (M20)
Electrical Supply and
Connection (L)
Connection (G)
Wiring Inlets on top
Wiring Inlets (M20)
A
Liquid
Gas
D
Line
Line
B
H
E
E
(L)
(G)
I
C
M
F
25
Model
VRf hp1000dXE
VRf hp1500dXE
VRf hp2000dXE
a (mm)
1300
1825
2350
K
b (mm)
605
1225
1793
225
Inserts for M10 drop rods
1.5m only
AIR IN
C (mm)
-
655
918
4 for 1m unit, 6 for 1.5m/2m units
45
45
Use all drop rod holes !
15
d (mm)
898
1398
1904
AIR OUT
E (mm)
-
699
952
20mm hole for gravity or pumped
f (mm)
182
222
204
condensate disposal (if cooling)
468
g
5⁄8 in.
5⁄8 in.
7⁄8 in.
h (mm)
442
333
299
i (mm)
253
267
258
J (mm)
359
359
334
k (mm)
80
45
80
l
1⁄2 in.
1⁄2 in.
5⁄8 in.
M
-
570
875
1.5.87
Air Conditioning
VRF HP DXE Heat Pump Air Curtain
