1.5.84
Taking full advantage of heat recovery technology, the Mitsubishi Electric booster unit (pWfy-p100VM-E-bU)
PWFY-P-VM-E-BU
can achieve a flow temperature of up to 70ºC and is an ideal solution for providing a hot water supply to
commercial buildings in an energy efficient manner.
VRF Sanitary Water Heater
Key Features
■ The benefit of having air conditioning as well as a hot water supply from a single system means that the unit
is suitable for a variety of applications
■ Simple addition of the booster unit to the existing air conditioning system
■ Perfect solution that eliminates the inconveniences of gas boiler installation, such as gas grid connection costs,
meter installation and maintenance costs
■ Uses the PAR-W21MAA controller
SANITARy WATER HEATER
PWFY-P100VM-E-BU
CapaCiTy (kW)
Hot water (nominal)*1
12.5
Hot water (UK)*2
8.0
pOWER iNpUT (kW)
2.48
COMpaTiblE OUTdOOR / CONdENsiNg UNiTs
pURy / pQRy
pipE siZE mm (in)
Gas
15.88 (5/8")
Liquid
9.52 (3/8")
Water Connection
pT 3/4 screw
Water pipe size
28
sOUNd pREssURE lEVEl (dba)
44
MaX WaTER TEMpERaTURE (ºC)
70
OpTiMUM WaTER flOW RaTE (m3/h)
1.5
WaTER pREssURE dROp aT OpTiMUM flOW RaTE (kpa)
22.5
WEighT (kg)
60
diMENsiONs (mm)
Width
450
Depth
300
Height
785 (800)
ElECTRiCal sUpply
220-240v, 50hz
phasE
single
RUNNiNg CURRENT (a)
10.66
fUsE RaTiNg (bs88) - hRC (a)
25
MaiNs CablE No. Cores
3
ChaRgE REfRigERaNT (kg) / CO2 EQUiValENT (t) R134a (GWP 1430)
1.1 / 1.6
Notes:
*1 Nominal conditions: Outdoor 7/6ºC , 65ºC inlet water temperature, 1.5m3/h water flow rate, 7.5m refrigerant pipe. (Please note this is a spot condition and not capacity over tank heat up).
*2 Typical capacity at -10ºCWB outdoor temperature for tank heat up.
