2.14

Climaveneta’s range of small to medium sized, cooling only chillers efficiently and easily adapt to a wide range of

i-BX

cooling capacities. The whole range contains inverter driven compressors for enhanced efficiency and control.

Air Cooled Chiller

Key Features

Packaged monobloc unit for easy installation

(4.3-12.9kW)

Full inverter technology with Mitsubishi Electric BLDC compressors

Extended cooling range, water outlet temperature -8 ~ 18°C, at ambient range of -10 ~ 45°C

Dynamic water set point, varies outlet temperature depending on ambient temperature

Cooling Only

EC water pump, relief valve, flow switch, safety valve and expansion vessel

Night function incorporated to reduce noise levels during the night

ErP 2021 compliant

Single Phase

Modbus connectivity option

Additional accessories available upon request

MODEL

i-BX 004 MHAN RV

i-BX 006 MHAN RV

i-BX 008 MHAN RV

i-BX 010 MHAN RV

i-BX 013 MHAN RV

POWER SUPPLY

V / ph / Hz

230 / 1 / 50

PERFORMANCE

COOLING CAPACITY ^*1

4.3

6.11

8.1

10.6

12.9

TOTAL POWER INPUT ^*1

1.55

2.12

2.82

3.64

4.74

EER ^*1

2.77

2.88

2.87

2.91

2.72

ESEER ^*1

4.2

4.36

4.7

4.29

4.55

COOLING ONLY (EN14511 VALUE)

COOLING CAPACITY ^{*1 *2}

4.3

6.11

8.11

10.6

12.9

EER ^{*1 *2}

2.82

2.92

2.74

ESEER ^{*1 *2}

4.53

4.6

5.08

4.34

4.69

COOLING ENERGY CLASS

SEASONAL EFFICIENCY IN COOLING (REG.EU 2016/2281) - AVERAGE CLIMATE CONDITIONS

SEER

4.38

4.43

4.93

4.39

4.78

PERFORMANCE (ƞs)^*3

172

174

194

172

188

HEAT EXCHANGER (USER SIDE)

WATER FLOW ^*1

l/s

0.21

0.29

0.39

0.51

0.62

MIN. SYSTEM WATER CONTENT

INLET / OUTLET CONNECTION SIZE

1"1/4

REFRIGERANT CIRCUIT

COMPRESSORS

N°

CIRCUITS

N°

REGULATION

STEPLESS

MIN. CAPACITY STEP

REFRIGERANT CHARGE R410A

1.45

2.1

3.55

3.6

3.65

CO2

EQUIVALENT

3.02

4.38

7.41

7.51

7.62

OIL CHARGE

0.35

0.4

0.87

1.4

ELECTRICAL

FULL LOAD POWER (F.L.I.)

1.9

2.7

3.7

4.9

6.5

FULL LOAD CURRENT (F.L.A.)

8.7

12.3

16.1

22.6

25.3

INRUSH CURRENT (S.A.)

FANS

QUANTITY

N°

AIRFLOW

m³/s

1.02

0.98

0.99

1.74

1.58

FANS POWER INPUT

0.12

*1 Plant (side) cooling exchanger water (in/out) 12°C/7°C; Source (side) heat exchanger air (in) 35°C.

NOISE LEVEL

*2 Values in compliance with EN14511-3:2013.

SOUND PRESSURE ^*4

dB(A)

*3 Seasonal energy efficiency of space cooling.

*4 Average sound pressure level at 10m distance, unit in a free field on a reflective surface;

SOUND POWER ^{*5 *6}

dB(A)

non-binding value calculated from the sound power level.

SIZE AND WEIGHT

*5 Sound power on the basis of measurements made in compliance with ISO 9614.

WIDTH ^*7

900

*6 Sound power level in cooling, outdoors.

DEPTH ^*7

370

420

*7 Unit in standard configuration/execution, without optional accessories.

HEIGHT ^*7

940

1240

Eurovent Certified Data

OPERATING WEIGHT ^*7

110

125

Climaveneta’s range of small to medium sized, cooling only chillers efficiently and easily adapt to a wide range of

i-BX

cooling capacities. The whole range contains inverter driven compressors for enhanced efficiency and control.

Air Cooled Chiller

Key Features

Packaged monobloc unit for easy installation

(10.7-35.1kW)

Full inverter technology with Mitsubishi Electric BLDC compressors

Extended cooling range, water outlet temperature -8 ~ 18°C, at ambient range of -10 ~ 45°C

Dynamic water set point, varies outlet temperature depending on ambient temperature

Cooling Only

EC water pump, relief valve, flow switch, safety valve and expansion vessel

Night function incorporated to reduce noise levels during the night

ErP 2021 compliant

Three Phase

Modbus connectivity option

Additional accessories available upon request

i-BX 010

i-BX 013

i-BX 015

i-BX 020

i-BX 025

i-BX 030

i-BX 035

MODEL

THAN RV

POWER SUPPLY

V / ph / Hz

415/3/50+N

PERFORMANCE

COOLING CAPACITY ^*1

10.7

13.3

15.5

20.6

25.0

29.8

35.1

TOTAL POWER INPUT ^*1

3.64

4.74

5.44

7.2

8.69

10.0

11.8

EER ^*1

2.94

2.81

2.85

2.86

2.88

2.98

2.97

ESEER ^*1

4.36

4.57

4.14

4.12

4.26

4.15

4.29

COOLING ONLY (EN14511 VALUE)

COOLING CAPACITY ^{*1 *2}

10.7

13.3

15.5

20.6

29.9

35.2

EER ^{*1 *2}

2.95

2.82

2.87

2.88

2.90

3.01

3.00

ESEER ^{*1 *2}

4.42

4.69

4.2

4.36

4.27

4.39

COOLING ENERGY CLASS

SEASONAL EFFICIENCY IN COOLING (REG.EU 2016/2281) - AVERAGE CLIMATE CONDITIONS

SEER

4.46

4.80

4.31

4.52

4.57

PERFORMANCE (ƞs)^*3

176

189

169

178

180

HEAT EXCHANGER (USER SIDE)

WATER FLOW ^*1

l/s

0.51

0.64

0.74

0.99

1.2

1.43

1.68

MIN. SYSTEM WATER CONTENT

INLET / OUTLET CONNECTION SIZE

1"1/4

1"1/2

REFRIGERANT CIRCUIT

COMPRESSORS

N°

CIRCUITS

N°

REGULATION

STEPLESS

MIN. CAPACITY STEP

REFRIGERANT CHARGE R410A

3.6

3.65

4.7

6.8

7.9

8.4

CO2

EQUIVALENT

7.51

7.62

9.81

14.19

14.62

16.49

17.54

OIL CHARGE

0.87

1.4

2.3

ELECTRICAL

FULL LOAD POWER (F.L.I.)

4.9

6.5

7.4

9.4

11.3

13.7

FULL LOAD CURRENT (F.L.A.)

INRUSH CURRENT (S.A.)

FANS

QUANTITY

N°

AIRFLOW

m³/s

1.74

1.7

1.64

2.26

3.76

4.2

4.86

FANS POWER INPUT

0.12

0.6

0.4

0.55

0.52

*1 Plant (side) cooling exchanger water (in/out) 12°C/7°C; Source (side) heat exchanger air (in) 35°C.

NOISE LEVEL

*2 Values in compliance with EN14511-3:2013.

SOUND PRESSURE ^*4

dB(A)

*3 Seasonal energy efficiency of space cooling.

*4 Average sound pressure level at 10m distance, unit in a free field on a reflective surface;

SOUND POWER ^{*5 *6}

dB(A)

non-binding value calculated from the sound power level.

SIZE AND WEIGHT

*5 Sound power on the basis of measurements made in compliance with ISO 9614.

WIDTH ^*7

900

1450

1700

*6 Sound power level in cooling, outdoors.

DEPTH ^*7

420

550

650

*7 Unit in standard configuration/execution, without optional accessories.

HEIGHT ^*7

1240

1390

1200

1700

Eurovent Certified Data

OPERATING WEIGHT ^*7

110

125

135

190

250

270

305

2.15

Chillers

i-BX Air Cooled Chiller Range
