High precision air conditioners are ideal for applications where high sensible cooling and close control
s-MEXT-G00 DX
of temperature and humidity are required.
s-MEXT takes advantage of more than 50 years experience of the RC brand within the I.T. Cooling market, coupled with
R410A Close Control System
Mitsubishi Electric renowned quality standards. The split cooling package consists of the indoor s-MEXT high precision
air conditioner connected to a Mr Slim R410A Power Inverter outdoor unit. The result is a full inverter split system, designed
according to the best quality standards and dedicated to the most reliable I.T. environments.
Key Features
High Efficiency - full Mitsubishi Electric inverter technology and EC plug fans
Small footprint
Pipe runs up to 100m
Trusted Mr Slim Power Inverter technology
Available in Upflow [over] and Downflow [under] variants
s-MEXT-G00 DX
s-MEXT-G00 DX
s-MEXT-G00 DX
s-MEXT-G00 DX
s-MEXT-G00 DX
s-MEXT-G00 DX
CRAC UNITS (Computer Room Air Conditioning)
006 S F1
009 S F1
013 S F1
022 S F2
038 D F3
044 D F3
COOLING CAPACITY (kW)*1
Total
6.79
10.1
11.9
22.5
38.8
42.4
Sensible
6.28
9.0
10.3
19.5
34.0
37.5
SHR*2
0.92
0.89
0.87
0.87
0.88
0.88
SYSTEM EER
3.90
4.01
3.01
2.88
3.15
2.62
EC SUPPLY FAN (no.)
1
1
1
2
1
1
AIRFLOW (m³/h)
2,000
2,500
2,800
5,000
8,800
10,000
NOMINAL EXTERNAL STATIC PRESSURE (Pa)
20
20
20
20
20
20
MAX EXTERNAL STATIC PRESSURE (Pa)
208
22
110
21
129
20
POWER INPUT (kW)*3
0.21
0.35
0.47
0.7
1.43
1.96
REFRIGERANT
R410A
R410A
R410A
R410A
R410A
R410A
REFRIGERANT CIRCUITS (no.)
1
1
1
1
2
2
AIR FILTERS (no.)
1
1
1
2
4
4
Extended filtering surface (m²)
0.68
0.68
0.68
1.05
1.76
1.76
Efficiency [ISO EN 16890] (COARSE)
60%
60%
60%
60%
60%
60%
SOUND LEVEL [ISO 3744] (dB(A))*4
Pressure Level
53
57
61
60
63
67
Power Level
69
73
77
76
79
83
POWER SUPPLY (V/Ph/Hz)
230 / 1 / 50
230 / 1 / 50
230 / 1 / 50
230 / 1 / 50
400 / 3 / 50+N
400 / 3 / 50+N
ABSORBED CURRENT (A)*3
1.5
2.1
2.7
3.0
2.1
2.8
STARTING CURRENT (A)
2.0
2.0
2.8
3.3
3.8
3.8
MAX ABSORBED CURRENT (A)
2.3
2.3
2.8
3.9
3.8
3.8
ELECTRICAL PANEL
Power Input (kW)
0.14
0.14
0.14
0.14
0.14
0.14
DIMENSIONS (mm)
Width
600
600
600
1,000
1,000
1,000
Depth
500
500
500
500
890
890
Height
1,980
1,980
1,980
1,980
1,980
1,980
NET WEIGHT (kg)
Upflow
103
106
110
165
237
237
Downflow
110
115
120
175
247
247
CONNECTIONS
Refrigerant pipes diameter - Gas (Ø Inch)
5/8"
5/8"
5/8"
1"
1"
1"
Refrigerant pipes diameter - Liquid (Ø Inch)
3/8"
3/8"
3/8"
1/2"
3/8"
1/2"
Condensate (Ømm)*5
19
19
19
19
19
19
Power Supply wiring Cable (no. x mm²)*6
3G1.5
3G1.5
3G1.5
3G1.5
5G1.5
5G1.5
OUTDOOR UNITS
PUHZ-ZRP60VHA2
PUHZ-ZRP100VKA3
PUHZ-ZRP125YKA3
PUHZ-ZRP250YKA3
2 x PUHZ-ZRP200YKA3
2 x PUHZ-ZRP250YKA3
SOUND PRESSURE LEVEL (dB(A))
Cooling
47
49
50
59
59
59
WEIGHT (kg)
70
116
125
135
135
135
DIMENSIONS (mm)
Width x Depth x Height
950 x 330 + 30 x 943
1050 x 330 + 40 x 1338
1050 x 330 + 40 x 1338
1050 x 330+40 x 1338
1050 x 330+40 x 1338
1050 x 330+40 x 1338
ELECTRICAL SUPPLY
220-240v, 50Hz
220-240v, 50Hz
380-415v, 50Hz
380-415v, 50Hz
380-415v, 50Hz
380-415v, 50Hz
Notes:
PHASE
Single
Single
Three
Three
Three
Three
The cooling capacity does not consider the supply fan motor thermal load.
OUTDOOR POWER INPUT (kW)
Cooling (nominal)
1.53
2.17
3.49
7.11
5.44
7.11
*1 Gross value based on return air of 27ºC - 47%RH; Ambient Temperature 35ºC;
STARTING CURRENT (A)
5
12
4
5
5
5
ESP=20PA; Interconnecting pipework length 5m.
MAX RUNNING CURRENT (A)
Cooling
19
26.5
9.45
21
19
21
*2 SHR = Sensible cooling capacity / Total cooling capacity.
FUSE RATING (BS88) - HRC (A)
25
32
16
32
32
32
*3 Corresponding to the nominal ESP=20Pa.
MAINS CABLE
No. Cores
3
3
5
5
5
5
*4 Sound pressure level on air return at 1m.
MAX PIPE LENGTH (m)
50
75
75
100
100
100
*5 Rubber pipe - referred to internal diameter.
MAX HEIGHT DIFFERENCE (m)
30
30
30
30
30
30
*6 Minimum section.
CHARGE REFRIGERANT (kg) / CO2 EQUIVALENT (t)
R410A (GWP 2088) - 30m
3.50 / 7.31
5.00 / 10.44
5.00 / 10.44
7.70 / 16.08
7.10 / 14.82
7.70 / 16.08
*7 For 75 to 100m please consult the service handbook.
MAX ADDITIONAL REFRIGERANT (kg) / CO2 EQUIVALENT (t)
R410A (GWP 2088)
1.20 / 2.51
2.40 / 5.01
2.40 / 5.01
4.80 / 10.02 (75m)*7
3.60 / 7.52 (75m)*7
4.80 / 10.02 (75m)*7
*8 Optional air protection guide is required for temperatures below -5°C.
GUARANTEED OPERATING RANGE (°C)
Max Temp
46
46
46
46
46
46
These units contain <HFC R410A [GWP100 2088]> fluorinated greenhouse gas.
Min Temp*8
-15
-15
-15
-15
-15
-15
s-MEXT-G00 DX R32 Close Control System
