The i-Life2 Slim Fan Assisted Radiator designed to work seamlessly with existing heating or renewable technologies.

i-LIFE2 Slim

Key Features

Stylish - At only 13cm deep, the sleek and elegant satin-white, wall mounted cabinet is designed to blend seamlessly into any setting

Fan Assisted Radiator

Flexible - Packed with advanced controls and functions, the i-Life2 Slim will work with traditional heating or renewable systems such as heat pumps

Easy to Use - Airflow is managed by deflectors at the top of the unit, which open and close automatically ensuring fast even heat distribution

MODEL

i-LIFE2 SLIM DLMV 80

i-LIFE2 SLIM DLMV 170

CAPACITY (W)^{*2 *6 *8}

500 / 780 / 880

1060 / 1660 / 2130

ELECTRICAL DATA

Electrical Supply

230v, 50Hz

Phase

Single

Fan Power Input (W) - (Lo-Mi-Hi)^{*1 *8}

0.7 / 4.6 / 10.7

1.62 / 10.1 / 19.0

WATER DATA

Water Flow Rate (l/min) - (Lo-Mi-Hi)^*2

1.2 / 2.4 / 2.4

3 / 4.8 / 6

Water Pressure Drop (kPa) - (Lo-Mi-Hi)^{*2 *8}

3 / 6 / 8

2 / 5 / 8

AIR DATA

Air Flow Rate (m3/h) - (Lo-Mi-Hi)^*1

51 / 93 / 125

122 / 221 / 277

SOUND DATA

Sound Pressure (dB(A)) - (Lo-Mi-Hi)^*3

24 / 35 / 41

26 / 36 / 42

Sound Power (dB(A)) - (Lo-Mi-Hi)^*4*7*8

33 / 44 / 50

35 / 45 / 51

DIMENSIONS (mm)^*5

Width

737

937

Depth

131

Height

579

i-Life2 Slim units are managed by a variable speed fan motor

WEIGHT (kg)^*5

that continuously modulates the fan speed

1. Room temperature 27°C d.b./19°C w.b.; Chilled water (in/out) 7/12°C.

2. Room temperature 20°C d.b.; Hot water (in/out) 45/40 °C.

Product Dimensions

i-LIFE2 SLIM DLMV 80

Product Dimensions

i-LIFE2 SLIM DLMV 170

3. Sound pressure level in free field on a reflective surface, 1m from fan front and 1m

from the ground. Non-binding value obtained from sound power level.

4. Sound power on the basis of measurements made in compliance with ISO 374

and Eurovent 8/2.

5. Unit in standard configuration/execution, without optional accessories.

6. Values in compliance with EN14511-3:2013.

7. Values in compliance with [REGULATION (UE) N.2016/2281].

8. Certified data in EUROVENT.

579mm

737mm

937mm

131mm

Energy Monitoring Packs

4.35

Heating

i-LIFE2 Slim Fan Assisted Radiator
