4.32
MELCloud is a cloud based solution for controlling your Mitsubishi Electric Ecodan heating
system either locally or remotely by PC, Mac, Tablet or Smartphone via the internet.
The set up and remote operation of your Ecodan heating system via MELCloud is simple and straight forward. All you need is
MELCloud Wi-Fi
a wireless connection where the Ecodan is located and an internet connection on your mobile or fixed device. To set up the
system, the router and the Ecodan Wi-Fi interface need pairing and this is done simply and quickly via the WPS button found
on all mainstream routers, or using access point pairing via a mobile phone.
Connectivity
Key Features
Access to remote maintenance and technical support
View and control your heating and hot water from anywhere in the world
Reports on energy use, temperature history and more
Featuring the award-winning
Live weather feed at location of Ecodan
Share / restrict access and control of the Ecodan system
Compatible with Alexa
Available for any FTC6 / FTC5 based system, new or retrofit using a MAC-567IF-E interface
MELConsole
Supported Ecodan Models
All Ecodan FTC6 / FTC5 systems have energy monitoring functionality as standard and the ability to connect to MELCloud.
A MAC-567IF-E Wi-Fi Interface is required to use MELCloud.
Wi-Fi Interface
MAC-567IF-E
DESCRIPTION
Wi-Fi Interface
CONNECT TO
Indoor Unit
MAX NUMBER OF UNITS
1
COMPATIBILITY
Ecodan FTC6 / FTC5
POWER SUPPLY
From indoor unit
DIMENSIONS (WxDxH) mm
79 x 18.5 x 44
CONTROL
On/Off
Mode
Heating Setpoint
Hot Water Boost
2-Zone Control
Holiday Mode
Timer
Frost Protection
MONITOR
On/Off
Mode
Heating Setpoint
Tank Temperature
Tank Target Temperature
Outside Temperature
Fault Codes
Consumed Electrical Energy
Produced Heat Energy
For a demonstration of
Mitsubishi Electric’s
Supported Hardware / Software
Supported Hardware / Software
MELCloud visit our website:
Tablets (Apps or Web Client)
Smartphones (Apps or Web Client)
Operating Systems
Internet Browsers (Web Client only)
Apple iPad / iPad mini
Apple iPhone
Android
Microsoft Internet Explorer
melcloud.com and click ‘Login’
Samsung Galaxy Tab / Note
Samsung Galaxy S
Apple iOS / OS
Google Chrome
Google Nexus
Google Nexus
Microsoft Windows
Apple Safari
Dell Latitude 10
Nokia Lumia
BlackBerry
Mozilla Firefox
Microsoft Surface
BlackBerry Z10
Opera
BlackBerry PlayBook
Please Note:
This is not definitive list of all compatible devices, other similar devices which use supported Operating Systems or Internet Browsers should also work either via dedicated Apps or via
Available for PC, Mac, Tablet or Smartphone
Web Browser / Web Client options. Please note that user experience may vary slightly depending on hardware and software combination.
4.33
Heating
MELCloud Wi-Fi Connectivity
