5.8

designed to supply fresh air into any commercial building whilst simultaneously

LGH-RVX-E

extracting stale air, the lossnay LGH-RVX-E units also recover valuable heat

energy for maximum efficiency, with total heat exchange.

Commercial Lossnay

Key Features

Clean, fresh air

Energy efficient heat recovery

Can be used in conjunction with Mr Slim and City Multi for highly efficient and effective operation

MODEL

LGH15RVX-E

LGH25RVX-E

LGH35RVX-E

LGH50RVX-E

LGH65RVX-E

LGH80RVX-E

LGH100RVX-E

LGH150RVX-E

LGH200RVX-E

ElEctRicAl POwER SUPPly

220-240V, 50Hz

RUNNiNG cURRENt (A)

SP1

0.10

0.12

0.13

0.15

0.17

0.29

0.33

SP2

0.15

0.16

0.26

0.39

0.36

0.50

0.70

0.88

SP3

0.24

0.28

0.54

0.59

0.90

0.83

1.20

1.75

2.20

SP4

0.40

0.48

0.98

1.15

1.65

1.82

2.50

3.71

4.88

iNPUt POwER (w)

SP1

SP2

123

153

SP3

131

151

200

311

400

SP4

140

165

252

335

420

670

850

AiRflOw (m³/h)^*2

SP1

125

163

200

250

375

500

SP2

125

175

250

325

400

500

750

1000

SP3

113

188

263

375

488

600

750

1125

1500

SP4

150

250

350

500

650

800

1000

1500

2000

AiRflOw (l/s)^*2

SP1

104

139

SP2

111

139

208

278

SP3

104

135

167

208

313

417

SP4

139

181

222

278

417

556

SPEcific fAN POwER (w/(l/s)) SP1

0.70

0.47

0.46

0.34

0.33

0.32

0.30

0.37

0.30

SP2

0.67

0.46

0.63

0.46

0.54

0.59

0.55

SP3

0.90

0.63

0.96

0.75

0.97

0.90

0.96

0.99

0.96

SP4

1.17

0.90

1.44

1.19

1.39

1.51

1.61

1.53

ExtERNAl StAtic

SP1

PRESSURE (Pa)

SP2

SP3

SP4

160

120

150

170

175

150

SOUNd PRESSURE

SP1

lEVEl (dBA)

SP2

SP3

SP4

34.5

tEmPERAtURE ExcHANGE SP1

88.5

89.5

EfficiENcy (%)

SP2

83.5

86.5

SP3

82.5

SP4

ENtHAlPy

Heating

SP1

83.5

82.5

ExcHANGE

SP2

78.5

EfficiENcy

SP3

75.5

73.5

(%)

SP4

69.5

71.5

68.5

72.5

cooling

SP1

85.5

SP2

74.5

72.5

SP3

74.5

69.5

72.5

SP4

66.5

70.5

wEiGHt (kg)

110

dimENSiONS (mm)

Width x Depth x Height

780 x 610 x 289

780 x 735 x 289

888 x 874 x 331

888 x 1016 x 331

908 x 954 x 404

1144 x 1004 x 404

1144 x 1231 x 404

1144 x 1004 x 808

1144 x 1231 x 808

dUct SizE (mm)

100

150

200

250

(SA,RA)250 (OA,EA)270 x 700

StANdARd filtER^*1

EU-G3

fUSE RAtiNG (BS88) - HRc (A)

Notes: Running Current, Input Power and Recovery Efficiency are based on the above airflow rate, power supply 240v, 50Hz. Sound Pressure Level measured at 1.5m under the centre of panel.

*1: EU-F7 filter available as optional parts. *2: Airflow tested to Japan industrial standard JIS B 8628. SP1, SP2, SP3 & SP4 relate to the fan speeds of the Lossnay RVX units i.e. fanspeed 1, 2, 3 & 4.

Accessories

DIMENSIONS

LGH-15RVX-E

DIMENSIONS

LGH-25-100RVX-E*

Remote Controllers

PZ-61DR-E

lossnay remote controller for lGH-RVx-E

Filters

PZ-15RFM-E

f7 filter for lGH-15RVx-E

PZ-25RFM-E

f7 filter for lGH-25RVx-E

PZ-35RFM-E

f7 filter for lGH-35RVx-E

* Please refer to the table below

for individual unit dimensions

PZ-50RFM-E

f7 filter for lGH-50RVx-E

PZ-65RFM-E

MODEL

DIMENSIONS

CEILING SUSPENSION FIXTURE PITCH

NOMINaL DuCt

REFERENCE

DIaMEtER

f7 filter for lGH-65RVx-E

PZ-80RFM-E

LGH-25RVX-E

780

735

289

768

782

150

f7 filter for lGH-80RVx-E / lGH-150RVx-E (2 sets)

LGH-35RVX-E

888

874

331

875

921

150

LGH-50RVX-E

888

1016

331

875

1063

200

PZ-100RFM-E

LGH-65RVX-E

908

954

404

895

1001

200

f7 filter for lGH-100RVx-E / lGH-200RVx-E (2 sets)

LGH-80RVX-E

1144

1004

404

1131

1051

250

LGH-100RVX-E

1144

1231

404

1131

1278

250

Weather Proof Housings

weather proof housings are also available

DIMENSIONS

LGH-150RVX-E

DIMENSIONS

LGH-200RVX-E

5.9

Ventilation

LGH-RVX-E Commercial Lossnay

5.10

lossnay LGH-RVXT-E mechanical Ventilation Heat Recovery (mVHR) systems are designed

LGH-RVXt-E

to supply fresh air into any commercial building, whilst simultaneously extracting stale air and,

most importantly, recovering valuable heat energy for maximum efficiency. the reduced height

of this model makes it particularly suitable for installation in ceiling voids.

Commercial Lossnay

Key Features

Clean, fresh air for improved air quality and comfort

Energy efficient heat recovery

Total heat exchange (sensible and latent)

Significantly reduced height

MODEL

LGH150RVXt-E

LGH200RVXt-E

LGH250RVXt-E

ElEctRicAl POwER SUPPly

220-240V, 50Hz

RUNNiNG cURRENt (A)

SP1

0.36

0.39

0.57

SP2

1.10

1.40

SP3

2.40

2.70

3.60

SP4

4.30

5.40

7.60

iNPUt POwER (w)

SP1

SP2

176

197

244

SP3

421

494

687

SP4

792

1000

1446

AiRflOw (m³/h)^*2

SP1

375

500

625

SP2

750

1000

1250

SP3

1125

1500

1875

SP4

1500

2000

2500

AiRflOw (l/s)^*2

SP1

104

139

174

SP2

208

278

347

SP3

313

417

521

SP4

417

556

694

SPEcific fAN POwER (w/(l/s)) SP1

0.46

0.40

0.47

SP2

0.85

0.71

0.70

SP3

1.35

1.18

1.32

SP4

1.90

1.80

2.08

ExtERNAl StAtic

SP1

PRESSURE (Pa)

SP2

SP3

SP4

175

SOUNd PRESSURE

SP1

lEVEl (dBA)

SP2

29.5

SP3

35.5

SP4

39.5

tEmPERAtURE ExcHANGE SP1

81.5

82.5

EfficiENcy (%)

SP2

82.5

80.5

SP3

80.5

SP4

ENtHAlPy

Heating

SP1

ExcHANGE

SP2

EfficiENcy

SP3

73.5

71.5

(%)

SP4

72.5

cooling

SP1

80.5

76.5

SP2

74.5

71.5

SP3

SP4

65.5

wEiGHt (kg)

156

159

198

dimENSiONS (mm)

Width x Depth x Height

1980 x 1500 x 500

dUct SizE (mm)

250 x 750

StANdARd filtER^*1

EU-G3

fUSE RAtiNG (BS88) - HRc (A)

Notes: Running Current, Input Power and Recovery Efficiency are based on the above airflow rate, power supply 240v, 50Hz. Sound Pressure Level measured at 1.5m under the centre of panel.

*1: M6 medium efficiency filter and F8 high efficiency filter available as optional parts. *2: Airflow tested to Japan industrial standard JIS B 8628. SP1, SP2, SP3 & SP4 relate to the fan speeds of the Lossnay RVXT units i.e. fanspeed 1, 2, 3 & 4.
