5.24
the Climaveneta Wizard Air Handling Units (AHUs) utilise mr Slim Power inverter heat pump
WizardX E-Ou
technology, efficient thermal wheel heat recovery technology and an integrated controls system,
making them highly advanced, flexible and efficient.
air Handling unit
Key Features
Mr Slim Power Inverter heat pump technology
Thermal wheel with hygroscopic coating
Constant volume EC plug fans
Easy air flow commissioning with selectable target air volume control
Fully integrated controls and single point power supply regardless of accessories
Units available in sections with all fixings, wiring, and electrical connectors included
MODEL
WIZaRDX E-Ou 3000
WIZaRDX E-Ou 5000
WIZaRDX E-Ou 7500
WIZaRDX E-Ou 10000
WIZaRDX E-Ou 12500
WIZaRDX E-Ou 15000
WIZaRDX E-Ou 20000
RAtEd AiR VOlUmE (m³/s)
0.83
1.39
2.08
2.78
3.47
4.17
5.56
AiR VOlUmE RANGE (m³/s)
0.56 - 0.83
0.97 - 1.39
1.53 - 2.08
2.22 - 2.78
2.92 - 3.47
3.61 - 4.17
4.31 - 5.56
ExtERNAl StAtic PRESSURE (Pa)
Standard fans
250
250
250
250
250
250
250
Uprated fans
400
400
400
400
400
400
400
cOOliNG cAPAcity (kw)
DX Coil Capacity
9.38
18.9
23.6
37.5
39.7
47.1
70.6
Wheel Recovery Capacity
24
39.4
57.7
77.8
96.2
115
160
Total Capacity
33.38
58.3
81.3
115.3
135.9
162.1
230.6
HEAtiNG cAPAcity (kw)
DX Coil Capacity
8.48
16.8
20.9
33.7
35.9
40.8
61
Wheel Recovery Capacity
30.9
49.9
73.6
98.9
123
147
206
Total Capacity
39.38
66.7
94.5
132.6
158.9
187.8
267
HEAt REcOVERy EfficiENcy (%)
79
75.5
74.7
75.1
74.7
74.6
78.9
SPEcific fAN POwER (SfPint) (w/(l/s))
0.96
0.77
0.76
0.75
0.74
0.8
0.91
SOUNd POwER lEVEl (dB(A))
Fresh/Outdoor
71
78
73
77
81
77
80
Supply
78
85
79
83
87
83
87
Return
69
78
71
75
81
74
79
Exhaust
76
85
77
82
87
80
85
Breakout
60
67
63
67
72
66
71
UNit dimENSiONS (wxdxH)*1 (mm)
3400x1000x1600
3400x1400x1600
3400x1500x2200
3400x1800x2200
3400x2000x2300
3800x2200x2360
3800x2500x2820
wEiGHt (kg)
850
1000
1150
1350
1600
1950
2300
StANdARd filtRAtiON
Fresh air 1st stage
iSO coarse 50% / G4
Fresh air 2nd stage
iSO ePm1 50% / f7 Bag filter
Return air
iSO coarse 50% / G4
cONStRUctiON
Profiles
60mm aluminium
Panels
45mm sandwich panels, galvinised steel sheets with a pre-plastified external finish
Insulation
45 kg/m3 density polyurethane foam
"EN1886 AcHiEVEd clASSES
d1(m), l3, f9, t3, tB4
(Deflection/Leakage/Filter bypass/Thermal transmittance/Thermal bridging)"
OPERAtiNG RANGES (°c dB)
Target Supply Air Setpoint
17 - 28
DX On Coil Cooling
15 - 32
DX On Coil Heating
5 - 28
ElEctRicAl POwER REQUiREmENtS
400VAc / 3ph+Positive Earth / 50Hz
cOmPAtiBlE OUtdOOR UNitS
Power Inverter (R410A)
2 x PUHz-zRP50
2 x PUHz-zRP100
2 x PUHz-zRP125
2 x PUHz-zRP200
3 x PUHz-zRP140
2 x PUHz-zRP250
3 x PUHz-zRP250
Standard Inverter (R410A)
Not compatible
Not compatible
Not compatible
2 x PUHz-P200
Not compatible
2 x PUHz-P250
3 x PUHz-P250
Note: Please refer to Mr Slim section for outdoor unit specification data. The specification data is based on the rated conditions below, at the rated air flows.
*1 Units in sections as an option will include extra profiles, increasing the weight and dimensions of the final unit.
RatED CONDItIONS
SuMMER
WINtER
iNdOOR
23ºc dB
50% RH
21ºc dB
50% RH
OUtdOOR
35ºc dB
50% RH
-5ºc dB
85% RH
